SHANGHAI SEA PRIDE SHIPPING SERVICES CO., LTD
E-mail: snp@sspshanghai.com
To: SnP Desk
Sub: Floating dock forsale from China – PPT delivery
Direct from very close local owner, for whom we had sold their sister docks recently, we can develop following fioating docks forsale from China.
Candidates:
1) abt 10,000 MT LT floating dock
Class: CCS domestic
Built(Finish construction): Oct, 2017, China (under operating now)
LOA: 129.5m (including the work platform)
Width (outer side): 40.0m
Width (inner side net): 36.0m
Height of Pontoon(Centre/Side): 3.5m/3.3M
Height of Dock wall in total (from bottom to up dock floor): 12.8m
Max Immersion depth: 9.0m
Crane: Nil. (but can try to install crane, the place for crane had been arranged by the owner)
Location: GuangDong province, of South China
Delivery: try one months time after dealfixed.
2) abt 2.600 MT LT floating dock (max 3,000mt)
built/delivery: Dec, 2025 (brand new condition)
Class: CCS, (river operating)
Max Length of Dock: 108.80m (including the working platform from both sides)
Length of pontoon: 97.20m
Outer width of dock: 33.00m
Inner width of dock: 29.40m
Depth of dock: 8.0m (from base line to weather deck)
Depth of pontoon: 2.3m(outer point); 2.4m(mid point)
Working draft: 2.0m
Height of dock wall: 5.7m
Designed immersion depth: 6.0m
Height of keel blocks: 0.7m (mid ship)
Frame space: 0.6m
Designed lifting capacity: rated at 2,600mt (max lift capacity: abt 3,000mt)
Workers: 10P
Material of hull: CCS-A marine steel plates
Ballast pump: 600m3/h x 22Kw x 18 unit electrical pumps
Remote-control electrical valves: DN350 x 18 unit No D/G fitted (shore power used), can install D/G with extracosts.
Delivery time: the dock is ready for launching in Oct/2025
can be arranged delivery by the end of Dec, 2025 (less than two months later)
this dock was designed and built with CCS class, it is in much better quality
3) 9,100 mt floating dock for ppt delivery
Built year: June, 2025, China (brand new condition, not in operating)
Class: ZC (currently for Chinese costal area of sea, can be modified to NON-IACS with sea-operating)
Flag: China
LOA: 148.0m
Length of Pontoon: 144.0m
Length of work platform: 2m x 2 = 4m (working platform can be increased, so that to increase the LOA)
Breadth of outer dock wall: 36.0m
Width of inner dock wall: 31.2m
Max immersion draft: 9.2m
Working draft at full loaded: 2.5m
Designed rated loading capacity: 9,100mt (max up to 10,000mt)
Crane: 10mt x 2 folding type Hdy. Crane (marine type with CCS product certificate)
20mt x 2 folding type Hdy. Crane (marine type with CCS product certificate)
D/E: one set of emergency D/G, 150Kw x 1 sets
Main D/G: NIL (but can be considered to install main D/G sets).
(the dock was currently designed to use shore power)
Anchors: 4 units Ballast pumps: 1440 m3/h x 75Kw x 4 sets
Delivery time: ready for delivery in Anhui Province, Yangtzge River
4) 8,500mt (max abt 12,000mt LCT) floating dock with CCS class, under construction in GuangDong province. delivery time is in about Jan/Feb 2026.
8,500mt Floating dock under contruction (max lift capacity: abt 12,000mt) CLASS: CCS
KEEL LAID/Delivery 2025-05/2026-01
Loa (include fore and aft platform) 150m
LENGTH OF PONTOON 136m
LENGTH OF FORE/AFT FLATFORM 8m/6m
LENGTH OF SIDEWALL 136m
WIDTH BETWEEN OUTSIDE WALL 46m
WIDTH BETWEEN FENDER 42.4m
WIDTH OF SIDEWALL 1.8m
HEIGHT 11.5m
DISTANCE FROM TOP DECK TO BASELINE 10.6m
DISTANCE FROM SAFETY DECK TO BASELINE 8m
DEPTH OF PONTOON AT CENTER LINE/INSIDE WALL 2.9/2.8m
MAX. DEPTH/FREEBOARD AT OUTSIDE WALL 8m
WORK DEPTH 2.5m
WATER DEPTH ABOVE KEEL BLOCKS WHEN MAX. IMMERSION DRAFT 4.4m
FREEDECK 6360m²
ANCHOR CHAIN & WINDLASS 4*5t anchor+165mØ52mm chain+4*45kw windlass
DESIGN CAPACITY 8500t
MAX LIFTING ≈12000t
PUMP 4*1440m³/hH13m
LIFTING TIME abt.90m
GENERATOR 1x150kw
Location: GuangDong province， south China
All detail given in good faith but wog.
pleased to hear your furtheu interest.
