SOUTH AFRICA

Longliner For Sale

Longline Vessel
Steel Built in 1995, Chantier Pirou Concareneau, France.
Class BV. exp. 1 July 2024
Registered Length of 30m
Hold Cap 250T
Beam 8.9m
Depth 4.06m
GRT 366T
NT 109T
Accommodation15
Main Engine MAN B&W 41DK-2450 1088BHP
Speed 10knots
Notes: Currently under refit, progress report available.
Inspections: Cape Town
Subject: Unsold and Available

Twende Africa Group
info@twendeafricagroup.com

Twende Africa Group of Companies (PTY) LTD or T.A.G. is a registered company based in Cape Town, South Africa with associated partner networks in Norway, UK, Netherlands, USA, Singapore, Australia and New Zealand. TAG Marine is an independent shipbroking company offering a complete range of shipbroking, business development and management services to vessel asset owners in the maritime industry.​

11.2m Patrol Boat New Demonstrator

LENGTH OVERALL: 11.5 metres
LENGTH HULL: 10.47 metres
BEAM MOULDED: 2.5 metres
DISPLACEMENT (Full Load): 5 749 kg
DISPLACEMENT (Lightship): 4 497 kg
DRAUGHT: (hull) 0.42 metres
CLASSIFICATION: Structural design to Lloyds SSC
SAFETY SURVEY: SAMSA CAT. B
CERTIFICATES: Compass Adjustment Certificate /Builders Certificate
FWD GUN PEDESTAL: Reinforcement in Cabin roof for 12.7mm gun Pedestal. Gunner platform over aft deck lockers.
AFT GUN PEDESTAL: Reinforcement 1 x 7,62mm gun Pedestal
PROPULSION: 2 x Yamaha 200HP Outboards
SPEED: 34 Knots
CREW:2 with options
NOTES: Optional Extras available on client’s request

Inspections: Cape Town, South Africa
Subject: unsold/available

Twende Africa Group
info@twendeafricagroup.com

Twende Africa Group of Companies (PTY) LTD or T.A.G. is a registered company based in Cape Town, South Africa with associated partner networks in Norway, UK, Netherlands, USA, Singapore, Australia and New Zealand. TAG Marine is an independent shipbroking company offering a complete range of shipbroking, business development and management services to vessel asset owners in the maritime industry.​

Twende Africa Group of Companies (P.T.Y.) L.T.D. or T.A.G. is a registered company based in Cape Town, South Africa, with associated partner networks in Norway, the U.K., the Netherlands, the U.S.A., Singapore, Australia and New Zealand. T.A.G. Marine is an independent shipbroking company offering a complete range of shipbroking, business development and management services to vessel asset owners in the maritime industry.​

info@twendeafricagroup.com

NEW VESSEL LISTING
Crew Boat

CLASSIFICATION / FLAG
Flag FRENCH
Trading area 20 miles from shore
Classification society BV for free board
Class ship type Crew Transfer/Survey/Supply Vessel
Class notation Previously UK – Workboat Code Category 2PRINCIPAL DIMENSIONS
Length o.a. 15,00 m
Breadth o.a. 6,3 m
Draft 0,9 m
GRT 15,6
Max. deck load 1,5 ton/m2
Max. 6 ton total
Free deck space Tot. 14 m2
Fwd. 8 m2
Aft 6 m2
Cargo Capacity Fwd. 0,750 ton
Aft 1,5 ton
Max. Deadweight 4 ton
Maximum speed 22 knots – 220 L/h
Service speed 19 knots – 180 L/h
Range 255 Nm at 19 kts

ACCOMMODATION
Passenger fully airconditioned
12x suspension seats for passengers
Crew 2x

NAVIGATION AND COMMUNICATION SYSTEMS
GMDSS A1
Safety & Rescue Sea Marshall Search and Rescue System
Jason’s Cradle
Rescue zone

MACHINERY / PROPULSION
Main engines 2x Scania DI12-60M
Power output 2x 441 kW
Propulsion 2x Waterjet Ultra Dynamics
Auxiliary engines 1x Stamford 230V/50Hz 16,5 kVA

DECK EQUIPMENT
Hydraulic deck crane Optional
Survey beam Positioned at PS deck house (optional)

TANK CAPACITIES
Fuel 2x 1275 Ltr.
Freshwater 200 Ltr.

Inspections: Reunion Island.
Subject: BOD Approval unsold/available

The Managing Director or whom it may concern,

Dear Sir/Madam,

ASD Tug open for sale
Year Built: 2009
Bollard Pull: 60
Engine BHP: 5,200
Class Status: Layed-up
Location: West Africa

Thank you in advance for your expression of interest.

Kind Regards,

Shipside International Sales Team.
s.p@shipsidebrokers.com

The Managing Director or Whom it may Concern,

Dear Sir/Madam,

Tug open for sale
Built: 1986 in Europe
BHP: 2604
Bollard Pull: 30 tons
Accom: 12 bunks
Lloyds class valid till end Nov 2022
Location: West Africa

For expression of interest, please reply email accordingly

Kind Regards,

Tug Sales Team
s.p@shipsidebrokers.com

The Managing Director or whom it may concern,

Dear Sir/Madam,

ASD Tug open for sale
Year Built: 2009
Bollard Pull: 60
Engine BHP: 5,200
Class Status: Layed-up
Location: West Africa

Thank you in advance for your expression of interest.

Kind Regards,

Shipside International Sales Team.
s.p@shipsidebrokers.com

Twende Africa Group of Companies (PTY) LTD or T.A.G. is a registered company based in Cape Town, South Africa with associated partner networks in Norway, UK, Netherlands, USA, Singapore, Australia and New Zealand. TAG Marine is an independent shipbroking company offering a complete range of shipbroking, business development and management services to vessel asset owners in the maritime industry.​

VESSEL LISTING

Longliner

Description
A steel boat about 38 meters in length was previously used as a seismic vessel and side trawler. It once housed 14 crew members, i.e.
The captain’s courters, seven men bunker for the officials and six men bunker for the rest of the crew. A four-person bunker was later installed, which increased the current number from 14 to 18 crew members.

Scope of Work – Completed 2019
• Shelter deck with railings covering half of one side of the vessel.
• Fishing completely re-insulated with marine ply and fibreglass-coated marine plywood. (size about 700 x 8.5 x 4m)
• Old mast pole was removed and replaced with a smaller mast, and the mast pole
• New 4 men’s bunker
• Electrical system converted from old fuse system to circuit breaker system
• Complete Electrical system refurbished to comply with SAMSA standards
• Main deck area removed and replaced with brand new checked steel plates
• New blast freezer with two blowers fully insulated with hangers for bait and extra storage.
• Old auxiliary engines and alternators were replaced with modern Laval engines and alternators.
• Exhaust system was renovated and added, complying with SAMSA standards
• All fresh water pipes and valves in the engine room replaced
• Safety survey was done in 2018 and passed by SAMSA rules
• Water tanks in the engine room cleaned and covered with cement slush
• Stern water tank cleaned, water blasted and painted with special water guard paint and primer
• Alarm system checked and repaired where necessary
• All valves checked, repaired or replaced accordingly
• Boat painted using the 7-step repair and paint process
• All lights replaced with new water-resistant fluorescent systems.
• Satellite phone installed
• New computer and navigational software
• Air conditioners replaced with new ones (galley, Aft accommodation & bridge)
• Crane fitted with brand new control valve

Outstanding Work
The crane cable will have to be replaced Large industrial fridge for the galley.
Magnetic compass to be replaced
Industrial hob and stove
Old air cons are to be replaced in FRWD accommodation.
A forward storage compartment is to be fitted with wood floor and shelving.

Vessel Particulars
Type: Longliner ex Dutch Beam Trawler / Guard Chase
Built: 1980 Netherlands
Refit: 2019 South Africa
Flag: SAMSA
Tonnage: 310 GRT
Dimensions: Loa 36,5 x Beam 8,0 x Depth 4,40 str
Main engine: 2000 bhp Deutz
Propeller: fixed propeller (FPP) 4 blades Kort nozzle
Aux. Engine two (2) Iveco, 80 Kw AC generator, 1 x DAF 48Kw, Emergency Gen 1 x Perkins, 32Kw
Bunkers: Fuel capacity: 95.244L
Freshwater capacity:20 000L
Water Maker: 1t/day
Electronics: All modern electronic equipment.
Accommodation: for 18 men

+++

Inspections: South Africa
Subject: BOD Approval unsold/available

The Managing Director or whom it may concern,

Dear Sir/Madam,

ASD Tug open for sale
Year Built: 2009
Bollard Pull: 60
Engine BHP: 5,200
Class Status: Layed-up
Location: West Africa

Thank you in advance for your expression of interest.

Kind Regards,

Shipside International Sales Team.
s.p@shipsidebrokers.com

Twende Africa Group of Companies (PTY) LTD or T.A.G. is a registered company based in Cape Town, South Africa with associated partner networks in Norway, UK, Netherlands, USA, Singapore, Australia and New Zealand. TAG Marine is an independent shipbroking company offering a complete range of shipbroking, business development and management services to vessel asset owners in the maritime industry.​

VESSEL LISTING – REMINDER!

28 Meter Hake Longliner/Keen Seller Inviting Offers

The vessel is a steel-hulled type fishing vessel, with one deck, a raked stem, transom stern, four bulkheads and one mast.

The superstructure is fitted forward of amidships, the forecastle is enclosed, there is a shelterdeck aft of the accommodation, there is one hold below the main deck and the engine room is aft below the main deck and factory.

Registered length: 27.14 metres
Length overall: 28.945 metres
Length between perpendiculars: 26.25 metres
Breadth: 6.40 metres
Depth moulded: 3.40 metres
GRT: 184.50 tonnes
NRT: 55.35 tonnes
Lightship: 207.83 tonnes
Built: 1974, Sandock Austral, Bayhead, Durban
Crew: 25 men
Speed: 10 knots
Inspections: South Africa, Subj. Unsold and Available.

T.A.G. Marine
info@twendeafricagroup.com
